Please visit the SFP transceiver module page or contact our sales department by e-mail or telephone. Note: A large selection of SFP optical modules are available for the LFC-10GT-SFP.

#10gb media converter pdf

LC connector for SFP module (SFP transceiver NOT included)Įxternal 90-260V AC switching adapter with NEMA1-15(2 blades only), US type main plugĪC 90-240V power adapter is included in carton packageġ0-85% non condensing (Operating) 0-90% (Storage)įCC part 15, Subpart B, Class A, ANSI C63.4:2003 CE EN55022:2006, Class A EN55024:1998+A1:2001+A2:2003 LVD: EN 60 950-1:2001Īdditional information on LFC-10GT-SFP converter: PDF Datasheet PDF Installation Manual. Supports 1000Base-T/10GBase-T, transmission packet rate 14880000 per second. RJ45 copper IEEE 802.3an (10GBase-T) and IEEE 802.3z (1000Base-T) compliantġ0G SFP+ (10GBase-X) and Gigabit SFP (1000Base-X) compatible slot Technical specifications Copper interface:

#10gb media converter series

Aggregates into LFC-CH12 series chassis available with various power supplies PLANET XT-705A Media Converter is equipped with one 10G/5G/2.5G/1G/100BASE-T auto-negotiation port and one 10GBASE-X SFP+ slot.Supports IEEE 802.1Q Tag VLAN pass thru.Supports Q in Q double tagged frame transparent.

Forward 9k bytes in converter mode (fiber & copper port at the same speed).

Forward 2048 bytes (Max.) packets in switch mode (copper & fiber port in different speed).

1000Base-T/10GBase-T RJ45 to 1000Base-X/10GBase-X SFP+ slot converter.

It also includes a wall mounting solution for individual converters named LFC-WMK. The LFC-10GT-SFP 1G/10G media converter is a very affordable solution for 10G Ethernet media conversion.

This is the highest density attainable for unmanaged fiber media converters. Used with their compatible LFC-CH12 fiber optic chassis they can be aggregated up to 12 units in a 19" wide and only 1RU of height space only. LED indicators signal the power status of the converter, UTP Link and FX port Link. RJ45 port works at 10GBase-T speed or at 1000Base-T Gigabit speed with settings through DIP switches available for speed. The SFP+ port can work with any 10G rated SFP+ such as SR, LR, ER, ZR, BiDi, CWDM or DWDM type and does also accept regular Gigabit speed only SFP transceivers.

The LFC-10GT-SFP is a dual speed 1G/10GBase-T RJ45 port to dual speed 1G/10GBase-X SFP/SFP+ slot un-managed fiber media converter. LFC series are newest series of media converters. * Note: AC 90-240V power adapter is included in carton package.
